Project Description
Umacable High Quality DisplayPort to HDMI Adapter is an ideal solution for connecting the video output of a DisplayPort enabled Chromebook or laptop to an HDMI display. Converts DisplayPort digital video signal to HDMI digital video signal. Supports video resolutions up to 4K@30 (3840×2160, Ultra HD) and 1080P (Full HD), and flawless audio pass through for uncompressed digital 7.1, 5.1 or 2 channels. Built to DisplayPort 1.2 standards, this cable meets the requirements of high performance applications. High quality materials and construction ensure a lifetime of dependable performance. Fully-shielded conductors provide complete immunity to EMI/RFI interference, and 24-K gold plated connectors ensure superior signal transfer. This fully-functional, high bandwidth cable is tested to perform at industry standards and is backed by Umacable lifetime warranty.
Key Features
• Connect the video output of a DisplayPort enabled Chromebook or laptop to an HDMI display
• Convert DisplayPort digital signal to HDMI digital signal
• Support 4K@30 (3840×2160, Ultra HD) resolution
• Feature a built-in active IC chip to achieve better compatibility
Note: This is not a bi-directional adapter, can only convert signal from DisplayPort to HDMI
Product Specifications
| • Item No.: | UMDP1004 |
| • Available Length: | 0.2M |
| • Available Gauge: | 32AWG |
| • Color: | Black or Customized |
| • Nylon mesh: | Customized |
| • Ferrite Core: | Customized |
| • Connector: | Gold or Nickel plated |
| • Packing: | PE bag, Zip bag, Box, Hang card, Blister |
| • Approval: | RoHS Compliant |
| • Vendor : | Umacable |
Electrical Characteristics
• Nominal Velocity of Propagation – 21.6Gbps
• DC Resistance – 300V
• Dielectric Strength – AC 500V/minute
• Insulation Resistance – 100Ω
• Time Delay – 5.2ns/m (max)
Physical Characteristics:
• Minimum Bend Radius – 12mm
• Operating Temperature – 0℃ – 70℃
• Storage Temperature Range – -10℃- 80℃
• Approvals – RoHS, CE, UL Compliant
Conductor 1 (5 pair)
• Conductor Type – 32AWG Tinned Copper
• Insulation – Foamed PE SKIN
• Drain Wire – 32AWG Tinned Copper
• Shield – Aluminum Foil, 100% Coverage
Conductor 2 (5 conductors)
• Conductor Type – 32AWG Tinned Copper
• Insulation – HDPE
Overall Cable
• Drain Wire – 28AWG Bare Copper
• Foil Shield – Aluminum Foil, 100% Coverage
• Braided Shield – 16/6/0.12, Al/Mg
• Jacket – PVC, Black, O.D.: 5.5±0.2mm
Connector 1
• Connector Type – DisplayPort Male
• Pin Construction – Phosphor Copper
• Injection – ABS
• Plating – 1 µm Gold
Connector 2
• Connector Type – HDMI Type A Female
• Pin Construction – Phosphor Copper
• Injection – ABS
• Plating – 1 µm Gold
Product Support
• Download the Technical specifications
