Project Description
HDMI 2.0 panel mount coupler, female to female adaptor, #4-40 screw, supports the video resolutions up to 4K*2K@50/60 (2160p)
Part # : UMPM2001
Connector 1 : HDMI female
Connector 2 : HDMI female with screw
MOQ: 500 PCS
Lead time: 15-30 days
Umateck High Quality HDMI Female to Female Panel Mount Adapter is the perfect solution for combining two HDMI cables to achieve connectivity through a panel. This allows the user to provide display connectivity from a source that is contained within a secure location. The adapter is designed for minimal signal loss. It supports the video resolutions up to 4K*2K@50/60 (2160p). High quality materials and construction ensure a lifetime of dependable performance. 24-K gold plated connectors ensure superior signal transfer. This fully-functional, high bandwidth cable is tested to perform at industry standards and is backed by Umateck lifetime warranty.
Key Features
• High Speed HDMI Female to Female Panel Mount Adapter
• The screw design helps to connect the device tightly
• Convenient way to combine two HDMI cables through a panel without any signal loss
• Bandwidth up to 18Gbps
• 4K@50/60 (2160p), which is 4 times the clarity of 1080p/60 video resolution
• 3D video, Deep Color and x.v. Color™
HDMI Panel mount coupler female to female adaptor
| Part # | UMPM2001 |
|---|---|
| Brand Name | Umateck |
| Category | HDMI Panel mount coupler female to female adaptor |
| Length | Adapter, without cable |
| Color | Black |
| Approval | CE, RoHS, REACH |
| Warranty | Lifetime |
| Package | Zip bag , color box , blister or Customized |
Electrical Characteristics
• Open/Short/Intermittence – 100%
• Hi-Pot – AV 150V, 0.01S
• Insulation Resistance – DC 200V, 0.01S, 10MΩ(Min)
• Conductive Resistance – 2 OHM (Max)
Physical Characteristics:
• Operating Temperature Range – -20℃- 80℃
• Storage Temperature Range – -25℃- 85℃
• Approvals – RoHS, CE, UL Compliant
Connectors
• Connector Type – HDMI Female
• Pin Construction – Phosphor Copper
• Injection – 45P PVC
• Plating – 1 µm Gold
