Umacable High Quality DisplayPort Cable is perfect for home theater or desktop audio video applications. Connects a DisplayPort equipped laptop or desktop to an HDTV, Monitor, Projector, Flat Panel Display, Digital CRT Display or other devices with DisplayPort input. It transmits both audio and video signals from your computer to a monitor for video streaming or gaming. Supports video resolutions up to 4K (3840×2160, Ultra HD) and 1080P (Full HD), and flawless audio pass through for uncompressed digital 7.1, 5.1 or 2 channels. Built to DisplayPort 1.2 standards, this cable meets the requirements of high performance applications. High quality materials and construction ensure a lifetime of dependable performance. Fully-shielded conductors provide complete immunity to EMI/RFI interference, and 24-K gold plated connectors ensure superior signal transfer. This fully-functional, high bandwidth cable is tested to perform at industry standards and is backed by Umacable lifetime warranty.
Key Features
• High Quality DisplayPort cable
• DisplayPort connector with latches provides a secure connection with a release button that must be depressed before unplugging
• Carries a digital audio/video signal
• Supports a High Bit Rate (HBR) bandwidth and up to a 4k resolution
• Built to DisplayPort 1.2 standard
Product Specifications
| • Item No.: | UMDP1001 |
| • Available Length: | 0.5m 1m 1.5m 1.8m 3m 5m 7.5m 10m |
| • Available Gauge: | 30AWG(1-3m) 28AWG( 3-7.5m) 26AWG (10m) |
| • Color: | Black or Customized |
| • Nylon mesh: | Customized |
| • Ferrite Core: | Customized |
| • Connector: | Gold or Nickel plated |
| • Packing: | PE bag, Zip bag, Box, Hang card, Blister |
| • Approval: | RoHS Compliant |
| • Vendor : | Umacable |
Electrical Characteristics
• Nominal Velocity of Propagation – 21.6Gbps
• DC Resistance – 300V
• Dielectric Strength – AC 500V/minute
• Insulation Resistance – 100Ω
• Time Delay – 5.2ns/m (max)
Physical Characteristics:
• Voltage Rating – 30V
• Maximum Bend Radius – 90mm
• Temperature Rating – 80℃
• Operating Temperature Range – -20℃- 80℃
• Storage Temperature Range – -25℃- 85℃
• Approvals – RoHS, CE, UL Compliant
Conductor 1 (5 pair)
• Conductor Type – 30AWG Bare Copper
• Insulation – Foamed PE SKIN
• Drain Wire – 30AWG Bare Copper
• Shield – Aluminum Foil, 100% Coverage
Conductor 2 (4 conductors)
• Conductor Type – 30AWG Bare Copper
• Insulation – HDPE
Overall Cable
• Drain Wire – 30AWG Bare Copper
• Foil Shield – Aluminum Foil, 100% Coverage
• Braided Shield – 16/5/0.12, Al/Mg
• Jacket – PVC, Black, O.D.: 6.0±0.2mm
Connectors
• Connector Type – DisplayPort Male
• Pin Construction – Phosphor Copper
• Injection – ABS
• Plating – 1 µm Gold
